To secure your charging on that house battery, the voltage sensitive relay has you protected.
The Voltage Sensitive relay allows charging of a second battery on a dual battery system. When your house battery reaches a certain voltage, the relay engages, allowing charge to the second battery.
When charging stops and voltage reduces below a certain value, the relay automatically isolates the second battery, ensuring that charge is prioritized to the house battery.
Digital circuitry provides superior reliability and extremely low power consumption.
Sizing and specs
- Total height 57mm
- Total width 69mm
- Total length 69mm
- Voltage 12V
- Current rating 125A
